| Specification | Details |
|---|---|
| Cable Type | CAT6 UTP (Unshielded Twisted Pair) |
| Conductor Material | 100% Bare Copper |
| Conductor Diameter | 0.57mm ± 0.02 (23 AWG Solid) |
| No. of Pairs / Conductors | 4 Pairs / 8 Conductors |
| Insulation Material | High-Density Polyethylene (HDPE) |
| Inner Jacket | PVC (Flame Retardant, LSZH Optional) |
| Outer Jacket | HD PVC / LSZH (Optional) |
| Jacket Color | Grey / Blue / Black / Custom on Request |
| Cable Length | 305 Meters (Standard Box) |
| Bandwidth | Up to 250 MHz |
| Data Transmission Speed | 10/100/1000 Mbps (Gigabit Ethernet) |
| Compliance Standards | ANSI/TIA-568.2-D, ISO/IEC 11801, RoHS |
| Fire Retardant Rating | IEC 60332-1 |
| Temperature Range | -20°C to +70°C |
| Packaging | Wooden Reel / Pull Box |
| Application | LAN, CCTV, IP Phones, PoE Devices, Networking Infrastructure |
Key Features:
-
Dual Jacket Layer offers extra protection for outdoor/industrial use
-
100% bare copper provides excellent conductivity and minimal signal loss
-
Supports Gigabit Ethernet, PoE, and high-speed transmissions
-
Flame retardant and weather-resistant jacket options
-
Ideal for long-distance structured cabling, CCTV, and data centers
