| Specification | Details |
|---|---|
| Product Type | PLC (Planar Lightwave Circuit) Splitter |
| Configuration | 1×8 |
| Connector Type | SC/PC |
| Fiber Type | Single Mode (G.657A1 / G.652D) |
| Input / Output Ports | 1 Input, 8 Outputs |
| Operating Wavelength | 1260 ~ 1650 nm |
| Insertion Loss (Typical) | ≤ 10.5 dB |
| Return Loss | ≥ 50 dB (SC/PC) |
| Uniformity | ≤ 1.0 dB |
| Polarization Dependent Loss | ≤ 0.2 dB |
| Directivity | ≥ 55 dB |
| Operating Temperature | -40°C ~ +85°C |
| Storage Temperature | -40°C ~ +85°C |
| Package Type | Mini Steel Tube / ABS Box / LGX Module / Rack Mount |
| Cable Length | Standard 1 Meter (Customizable) |
Key Features:
-
Even signal distribution to 8 output ports
-
Factory-assembled SC/PC connectors for easy integration
-
Low insertion and polarization-dependent loss
-
Excellent reliability and optical performance
-
Compact and lightweight design for easy deployment
-
RoHS compliant and Telcordia GR-1209/1221 certified
